I've updated / upgraded the V-One gauge for the B727...lots of new stuff!
Now available in the Avsim library, search for:
V-One Gauge for Boeing 727-100/200/F (Complete) New features in this version are in indicated in '
blue'.
Twenty call-outs sounds integrated into gauge
(13 new call-outs). Take-off V-Speeds calculated for Flaps 5, 15, or 25 with temperature and altitude adjustments.
Take-off speed bugs and Command speed bug automatically set for: V1/Vr, V2, V2 + 15.
Flaps-up maneuvering speed (clean speed) bug set after flaps-up. Optimum altitude and optimum EPR (EPR calc for M.80) are continually calculated.
Gross Weight overage will display in 'red' text.
Tooltip indicates overweight value (LB/KG). Take-off trim calculated for current gross weight.
Maximum Climb Thrust (MCT) calculated based on current TAT temperature.
Current EPR displayed adjacent to MCT for ease of use during climb phase. Display units can be toggled between LB and KG (default LB).
Outside air Temperature can be toggle between Fahrenheit and Celsius.
Resettable fuel use.
Resettable flight timer.
Selectable Vref landing configurations, Vref30 (default) or Vref40.
Approach / landing speed bugs and Command speed bug automatically set for: Vref, Vref + 5, Vref + 15. ZFW, Fuel, CG, Gross Weight and Barometric Pressure MSL (QNH) displayed.
'Barometer Set' call-out occurs when pressing keyboard letter 'B' (V-One gauge must be open).
Airspeed gauge enhanced: CMD speed bug colorized orange and notch added for visibly of tick marks below.
Decision Height adjustment now on Data Card in hidden click-spot located on upper right corner.
Now installation to a single location will work for all variants.
